IBest POE HAT for Raspberry Pi 4B 3B+,802.3af/at-compliant,Power Over Ethernet HAT (C) Expansion Board for Raspberry Pi 3B+ 4B,with Cooling Fan and Heatsink
Thumbnail 1Thumbnail 2Thumbnail 3Thumbnail 4Thumbnail 5Thumbnail 6Thumbnail 7Thumbnail 8Thumbnail 9

IBest POE HAT for Raspberry Pi 4B 3B+,802.3af/at-compliant,Power Over Ethernet HAT (C) Expansion Board for Raspberry Pi 3B+ 4B,with Cooling Fan and Heatsink

4.3/5
ID del producto: 320411857
Transacción segura
25W Power Output
🔌802.3af/at Compliant
🌬️Active Cooling Fan
Comprados juntos con frecuencia

Descripción

⚡ Power Up Your Pi with Style!

  • POWER YOUR PROJECTS - Seamlessly integrates with Raspberry Pi 3B+/4B for PoE capabilities.
  • EXPAND YOUR HORIZONS - Includes a USB-A port for powering additional devices effortlessly.
  • COMPACT LIGHTWEIGHT - Weighs only 60g, making it perfect for portable projects.
  • FUTURE PROOF YOUR SETUP - Designed for stability and longevity with fully isolated SMPS technology.
  • STAY COOL UNDER PRESSURE - Equipped with a high-speed active cooling fan for optimal performance.

The IBest POE HAT for Raspberry Pi 4B and 3B+ is a cutting-edge expansion board that enables Power Over Ethernet capabilities, ensuring stable power delivery while enhancing your Raspberry Pi experience with an active cooling fan and additional USB-A port for external devices.

Presupuesto

BrandIBest
Package Dimensions8.1 x 7.1 x 2.9 cm; 60 g
Item model numberPower over Ethernet HAT (C) for Pi
ManufacturerIBest
Processor BrandRaspberry Pi
Processor Count1
Connectivity Typeethernet
Wireless Type802.11b
Wattage25 watts
Operating SystemRaspberry Pi OS
Are Batteries IncludedNo
Item Weight60 g
Guaranteed software updates untilunknown

Reseñas

4.3

Todo de compras verificadas

G**E

Plug it in and use it!

The function of this device is to provide power (in this case 5v DC) to a Raspberry Pi over the Ethernet cable that's plugged into the Pi 4's on-board Ethernet port. To use it, you'll also need a couple of decent quality Ethernet cables and a Power over Ethernet injector. I've included links to the equipment I use with this (also bought on Amazon) as examples.This hat plugs into the Raspberry Pi's GPIO header and has a few extra connectors (pogo pins) that line up nicely with little pads on the Raspberry Pi PCB. No soldering is required, and there's no software setup either.The Power over Ethernet Injector plugs into my network hub (for the data) and the mains (for the power) and uses the spare cores in the Ethernet cable to send power to the Pi. This power is sent up your Ethernet cable at a higher voltage than the Pi can use, and the hat handles the conversion back to 5v DC needed by the Pi to work.I use this on a Raspberry Pi 4 that lives in our loft, where there is no mains supply. It happily drives the Pi 4, a software-defined radio and a GPS receiver without any loss in data rate. You simply plug it all in, and it just works.The box contains some basic instructions, as well as some standoffs to keep the hat mounted firmly against the Raspberry Pi (though they weren't suitable for my purpose, so I bought some separately).My PoE Injector: https://smile.amazon.co.uk/gp/product/B08LQP8CYD/My Ethernet Cables: https://smile.amazon.co.uk/gp/product/B003ZB7NE2/

R**E

An excellent board for Pis in remote locations

I use my Raspberry Pi3B as a Home Assistant hub, and to get the strongest signal with the Zigbee dongle, it needs to be central in the house. However, the best location isn't where there are any mains sockets, so I decided to run a single ethernet cable there and use a PoE switch to power the Pi.The hat fits easily onto the IO pins, but still has a pass-through for the pins, so they're available for other uses. The pack includes some standoffs to keep the boards secure.The hat comes with a fan to keep air moving around and the PI cool. The slight downside is that if you have heat sinks attached to the chips on the Pi, there is a large component on the hat that interferes slightly. You can raise the hat a few millimetres to get it to fit, while still maintaining the electrical connection.The hat does make the Pi too tall for many off-the-shelf cases, but you can get sometaller 3D printed cases.

D**Y

It Just Works

I love that the board clips onto the board, while allowing use of all the breakout pins.Using my old Netgear POE 8 port switch was ample for this to work.It just worked.Note my load on the device is just running HomeAssistant. No other hardware.

T**S

The fan lasted 5 days, the rest 6 weeks.

It's powering a pi 3b+ running Home Assistant from a SATA SSD and Zigbee coordinator, so not exactly heavily loaded. Power is stable, and I don't get the red low voltage light ever, but the fan lasted about 2 weeks before the bearings died. CPU was 35c before, and is now 55c until I get around to replacing it.EDIT: scratch that, the whole thing died. Somehow it's still within the standard returns period so I have started that and hopefully I'll get my refund without issue.

D**Y

Nice poe hat

Really good quality poenhat with great understanding and functional for raspberrypi aswell as component being brill quality

V**.

Pas mal

Le produit fonctionne parfaitement, il permet d’alimenter mon Raspberry Pi 4 en POE, le petit ventilateur est appréciable.Personnellement, les pins qui dépassent me dérangent car le chapeau du boîtier original n’est pas utilisable.Après quelques semaines d’utilisation, le petit ventilateur commence à faire du bruit, remplacement à envisager.
